CPU: Intel® Core™ i3-1215U / i5-1345U
Chipset: Alder Lake (i3) / Raptor Lake (i5)
TDP: 15W
Motherboard: 120 × 120 mm
OS: Windows 10 / Windows 11 / WES 10 / Linux
PXE Boot: Supported
Audio: Intel HD Audio, USB Audio, HID
Memory:
1× / 2× SO-DIMM DDR5, up to 64GB
Network & Graphics:
2× Gigabit LAN (Realtek RTL8111)
Intel UHD Graphics (i3) / Intel Iris Xe (i5)
Mini PCIe: Wi-Fi + BT / 3G / 4G
Antennas: 2× Internal + 2× External
I/O Interface:
Power Switch
DC IN 12V–19V
4× USB 2.0, 4× USB 3.0
HDMI 1.4, VGA
2× RJ45 LAN
2× DB9 RS232
MIC-IN, Speaker-OUT
Storage:
1× M.2 2280 NVMe/NGFF
1× SATA 3.0 (2.5" HDD/SSD)
Power & Environment:
AC Input: 100–240V, 50/60Hz
DC Output: 12V–19V
Operating Temp: -20°C to +60°C
Storage Temp: -30°C to +70°C
Humidity: 10%–90% RH (non-condensing)
Mechanical:
Size: 193.9 × 127 × 57.2 mm
Weight: Net 1 kg / Gross 1.5 kg
Chassis: Aluminum alloy (Black)
Mounting: Baseplate (4 holes)
Cooling: Fanless
System Functions:
Auto Power On (AWAL), Wake-on-LAN, RTC, Watchdog
Package Contents:
Standard: Mini PC, Power Adapter, Power Cord, Screws
Optional: Wi-Fi Antennas, User Manual, Long Screws
